CPI Diplexer 111422-01

CPI 111422-01 Ku-Band 2-Port Diplexer | 10.7–12.75 GHz Rx / 17.3–18.4 GHz Tx

The CPI 111422-01 Ku-band diplexer is a high-performance 2-port unit designed for linear polarized SATCOM applications. It features low insertion loss (≤0.25 dB), high Tx/Rx isolation (≥85 dB), and cross-polarization discrimination of ≥35 dB. Built for 2 kW power handling, the unit is housed in a robust, weather-resistant enclosure with precision-plated flanges.

Key Features:

Frequency Range:
Rx: 10.7–12.75 GHz
Tx: 17.3–18.4 GHz
2-Port, Linear Polarization Design
High Isolation: ≥85 dB Tx/Rx & Rx/Tx
Low Insertion Loss: ≤0.25 dB
Cross-Pol Discrimination: ≥35 dB
Power Handling: 2.0 kW
Finish: Zinc-nickel and chromate conversion coated; white exterior
