CPI Diplexer 112358-01

CPI 112358-01 Ku-Band 2-Port Diplexer | High-Isolation Linear Polarized

The CPI Model 112358-01 is a high-performance Ku-Band 2-port diplexer designed for satellite communication systems utilizing linear polarization. It offers excellent isolation between transmit and receive paths across extended Ku-Band frequencies, making it ideal for dual-band operation with minimal interference. Built for reliability, it features rugged environmental sealing and a corrosion-resistant finish.

Key Features:

Frequency Band:
• RX: 10.7–12.75 GHz
• TX: 17.3–18.4 GHz
Insertion Loss:
• RX: ≤ 0.25 dB max
• TX: ≤ 0.25 dB max
VSWR:
• RX: 1.25:1 max
• TX: 1.25:1 max
Isolation:
• TX/RX & RX/TX: ≥ 85 dB min
Cross-Polarization: ≥ 35 dB min
Sealed to 1.0 PSIG for pressurization
Finish: Zinc-nickel plated flange faces; white painted exterior (FED-STD-595 color 17875)
