CPI Diplexer 111185-01

CPI 111185-01 Ku-Band 4-Port Diplexer | 10.7–12.75 GHz Rx / 17.3–18.4 GHz Tx

The CPI 111185-01 is a high-isolation Ku-band 4-port diplexer tailored for linear polarized systems. It provides reliable separation of transmit and receive signals across 10.7–12.75 GHz (Rx) and 17.3–18.4 GHz (Tx), supporting high-power uplink/downlink operations with excellent isolation and low insertion loss—ideal for robust SATCOM environments.

Key Features:

Frequency Range:
   Rx: 10.7–12.75 GHz
   Tx: 17.3–18.4 GHz

Port Count: 4

Polarization: Linear

High Tx/Rx Isolation: Ensures signal integrity

Low Insertion Loss: Optimized for minimal signal degradation

Application: Ku-band linear polarized earth stations and satellite terminals
