CPI Diplexer 110163-14

CPI 110163-14 C-Band Rx-Only Feed | 3.6–4.2 GHz, Dual Circular Polarization

The CPI Model 110163-14 is a precision-engineered C-band receive-only feed operating from 3.6 to 4.2 GHz. Designed for dual polarization support (RHCP and LHCP), it features excellent axial ratio and low insertion loss for optimal satellite signal reception. With 0.5 PSIG sealing and chromate conversion coating, this model is well-suited for outdoor and long-term SATCOM installations.

Key Features:

Receive Band: 3.6–4.2 GHz (Rx-only)
Polarization: RHCP and LHCP
Insertion Loss: ≤0.20 dB
VSWR: ≤1.20:1
Axial Ratio: 1.3 (2.3 dB)
Pressurization: Sealed to 0.5 PSIG
Finish:
Flanges: Chromate per MIL-DTL-5541F, Class 1A
Exterior: White paint per FED-STD-595 (Color No. 17875)
