CPI 113735-09 X-Band 4-Port Diplexer | Circular Polarized
The CPI 113735-09 is a high-performance 4-port X-Band diplexer designed for satellite earth stations requiring circular polarization. It separates transmit and receive paths across 7.25–8.4 GHz with robust port isolation, making it ideal for high-reliability SATCOM applications.
Key Features:
Frequency Band:
• RX: 7.25–7.75 GHz
• TX: 7.9–8.4 GHz
Configuration: 4-Port
Polarization: Circular
Application: High-isolation transmit/receive separation for X-Band SATCOM systems
Mechanical Design: Engineered for durability and environmental sealing
CPI Diplexer 113735-09
- Receive Band
- 7.25–7.75 GHz
- Output Band
- 7.9–8.4 GHz
- Polarization
- CP
- Ports
- 4
