CPI 113735-10 X-Band 4-Port Diplexer | Circular Polarized
The CPI 113735-10 is a rugged, circular polarized 4-port diplexer built for X-Band satellite communication systems. It separates receive and transmit paths—supporting 7.25–7.75 GHz for RX and 7.9–8.4 GHz for TX—ensuring high isolation and efficient signal routing for mission-critical SATCOM applications.
Key Features:
Frequency Band:
• RX: 7.25–7.75 GHz
• TX: 7.9–8.4 GHz
Configuration: 4-Port
Polarization: Circular
Application: X-Band SATCOM uplink/downlink separation
High Isolation & Low Insertion Loss Design (based on CPI standards)
Sealed Construction for Environmental Protection
CPI Diplexer 113735-10
- Receive Band
- 7.25–7.75 GHz
- Output Band
- 7.9–8.4 GHz
- Polarization
- CP
- Ports
- 4
