CPI 114450-07 X-Band 2-Port Diplexer | Compact RF Signal Separator
The CPI 114450-07 is a 2-port X-Band diplexer engineered for satellite communication systems requiring precise separation between receive (7.25–7.75 GHz) and transmit (7.9–8.4 GHz) signals. This compact diplexer ensures low insertion loss and high isolation for efficient RF performance in demanding uplink/downlink applications.
Key Features:
Frequency Band:
• RX: 7.25–7.75 GHz
• TX: 7.9–8.4 GHz
Configuration: 2-Port
Compact & Reliable Design
Application: X-Band SATCOM transmit/receive isolation
High Isolation Between Paths (spec expected based on frequency spread)
Durable, Sealed Construction for Harsh Environments
CPI Diplexer 114450-07
- Receive Band
- 7.25–7.75 GHz
- Output Band
- 7.9–8.4 GHz
- Ports
- 2
