CPI Diplexer 112766-05

CPI 112766-05 X / Ku-Band Diplexer | High Isolation

The CPI 112766-05 is a compact X/Ku-Band diplexer designed for satellite systems requiring separate receive (X-band) and transmit (Ku-band) paths. It features low insertion loss and high isolation between channels, enabling robust performance for Earth station and airborne applications.

Key Features:

Receive Band (RX): 7.25–7.75 GHz (X-Band)
Transmit Band (TX): 10.7–12.75 GHz (Ku-Band)
High Isolation Design: Ensures minimal signal leakage between RX and TX paths
Applications: Suitable for dual-band satellite terminals and frequency-isolated systems
