Norsat ULC-1-50

$1,900.00

Universal LNB Controller

Reference: 10 MHz reference

Connector: N Type 50 Ohm

Control Interface: Switch Control Only

Quantity
Lead Time: 2 - 3 Weeks



Security policy



Delivery policy



Return policy

Norsat ULC-1-50 Universal LNB Controller with Internal Reference

The Norsat ULC-1-50 is a universal LNB controller with 50 Ohm N-type connectors and internal 10 MHz reference. It supports 13V/18V output, tone generation, and line length compensation for reliable LNB power and control in harsh RF environments.

Reference Signal: Internal 10 MHz
Output Voltages: 12.5 – 13.5 VDC / 17.3 – 18.7 VDC
Tone Frequency: 20 – 24 kHz
Tone Amplitude: 0.55 – 0.9 Vpp
Control Interface: Switch, cable, and line length compensation
Logic Levels: Low: 0–0.8 V, High: 2.5–7 V
Connector Type: 50 Ohm N-Connector
Output VSWR: max. 2.0:1
Output Current: max. 500 mA
Power Supply: +23 to +25 VDC
Current Consumption: 600 mA @ 24 VDC
IP Rating: IP66
Operating Temp: –30°C to +60°C
Dimensions: 130 × 95 × 30 mm
Weight: 0.66 kg

Made in Canada

ULC-1-50
Control Interface
Switch Control
Reference Signal
10 MHz internal
Connector Type
N (50 ohm)
