DEV 223x Active L-Band Combiners, 800-2450 MHz

DEV 223x Active L-Band Combiners, 800-2450 MHz

The DEV 223x Series Active L-Band Combiners provide 8:1, dual 8:1 or 16:1 RF signal combining for satellite ground stations, teleports, broadcast facilities and professional L-band networks. Available models include the DEV 2232, DEV 2233 and DEV 2235.

Operating across the extended 800-2450 MHz frequency range, these active combiners support 50 Ohm, 75 Ohm and mixed-impedance configurations. SMA, BNC and precision F female connectors can be selected independently for each group of eight inputs and the associated output.

DC-blocked input ports protect connected RF sources, while integrated RF sensing provides an adjustable threshold and LED alarm indication. Dedicated monitoring outputs and redundant AC power supplies support reliable operation in a compact 19-inch, 1 RU chassis.

Product Type: Active L-band combiners
Frequency Range: 800-2450 MHz
Available Configurations: 8:1, dual 8:1 and 16:1
Impedance: 50 Ohm, 75 Ohm or mixed impedance
Available Connectors: SMA female, BNC female or precision F female
Nominal Input Level: -10 dBm aggregated power
Damage Level: +10 dBm
Return Loss: Greater than 14 dB
Insertion Loss: 0 ±1.5 dB
Full-Band Flatness: ±1.0 dB
36 MHz Flatness: ±0.25 dB
Input Port Isolation: Greater than 25 dB
Intermodulation Distortion: Less than -40 dBc
Group Delay Distortion: Less than 0.5 ns within any 36 MHz
Monitoring Outputs: 50 Ohm SMA female
RF Sensing Threshold: Adjustable from below 0 dBm to above -50 dBm
Threshold Accuracy: ±3 dB
Alarm Indication: LED
Configuration Interface: Front-panel USB
Input DC Blocking: Yes
Power Supply: Redundant 100-240 VAC inputs
Power Consumption: Less than 35 VA
Chassis: 19-inch, 1 RU
Dimensions: 483 mm W x 44 mm H x approximately 260 mm D
Weight: Approximately 2 kg

Available Models

DEV 2232: 8:1 active L-band combiner with eight inputs and one output

DEV 2233: Dual 8:1 active L-band combiner with 16 inputs and two independent outputs

DEV 2235: 16:1 active L-band combiner with 16 inputs and one output

Model-Specific Performance

DEV 2232

Noise Figure: Less than 25 dB
Monitoring Level: Combined output level minus 35 dB, ±3 dB

DEV 2233

Noise Figure: Less than 25 dB
Monitoring Level: Combined output level minus 35 dB, ±3 dB

DEV 2235

Noise Figure: Less than 29 dB
Monitoring Level: Combined output level minus 39 dB, ±3 dB

Connector and Impedance Options

vCin50: Eight 50 Ohm SMA female combiner inputs

vCin50B: Eight 50 Ohm BNC female combiner inputs

vCin75: Eight 75 Ohm precision F female combiner inputs

vCin75B: Eight 75 Ohm BNC female combiner inputs

vCout50: One 50 Ohm SMA female combiner output

vCout50B: One 50 Ohm BNC female combiner output

vCout75: One 75 Ohm precision F female combiner output

vCout75B: One 75 Ohm BNC female combiner output

Key Features

• Active L-band signal combining from 800 to 2450 MHz

• 8:1, dual 8:1 and 16:1 configurations

• 50 Ohm, 75 Ohm and mixed-impedance configurations

• Flexible SMA, BNC and precision F connector options

• Independently configurable input and output interfaces

• DC-blocked RF input ports

• High isolation between input ports

• Dedicated monitoring output for each combiner

• RF sensing with adjustable threshold

• Front-panel USB configuration

• LED alarm indication

• Redundant AC power supplies

• Compact 19-inch, 1 RU rack-mount chassis
